Step by Step Design of 950TR HVAC Plant Room in Revit MEP

Step by Step Design of 950TR HVAC Plant Room in Revit MEP

MP4 | Video: h264, 1280×720 | Audio: AAC, 44.1 KHz
Language: English | Size: 4.54 GB | Duration: 6h 24m

What You’ll Learn

Bim / Revit Modelling

Bim / Revit Estimation

Bim / Revit Documentation

Chilled Water Pipe Sizing

How to Convert 2d Cad Layouts to 3d Bim Revit Model

Valves & Accessories Connections for Chiller , Pumps , Cooling Tower

3d Designing & Modelling of Hvac Plant Room

How to Work With Linked Cad Files

Get Hands on Experience on Real Project by ing the Revit Families Provided in This Course

Revit Mep Modelling Best Practices

Real Project Modelling

Revit Mep Secret Tips & Tricks

Understanding of Revit(Basic Level)


This Course Is Divided Into 3 Sections, Which Are

1. Design & Modelling

2. Project Estimation

3.project Documentation.

Detailed Course Syllabus Is as Follows:

Section 1 – Design & Modelling

1. Understanding Project Brief

2. Linking Cad File in Revit

3. Creating Architectural Elements(Floor/walls/foundations)

4. How to Add Materials on Equipments

5. Chilled Water Pipe Sizing (Carrier Std)

6. Placing Equipments(Chiller/pumps/cooling Tower)

7. How to Create Pipe Types

8. How to Create Piping Systems(Chws/chwr/cws&r)

9. Placement of Header Pipes

10. Adding Branch Connections to Chiller/pumps (Automatic & Manually)

11.chiller Hookup

12.pump Hookup

13.cooling Tower Hookup

14.placement of Valves & Accessories Required for Chiller , Pump ,cooling Tower.

Section 2 – Project Estimation

1. Introduction to Parameters

2. Classification of Parameters.

3. How to Create Shared Parameters.

4. Estimation of Total Pipe Quantity in Revit

5. Schedule Preparation for Chilled Water & Condenser Water Pipe.

6. Estimation of Total Pipe Cost Using Schedules (Boq Preparation).

7. Estimation of Total Accessories Quantity

8. Estimation of Total Valves Quantity.

9. How to Prepare a Detailed Chiller Schedule. to Prepare a Detailed Hvac Pumps Schedule to Prepare a Detailed Cooling Tower Schedule

Section 3 – Project Documentation

1. How to Create & Edit a Tag

2. Working With Texts

3. How to Detail a Floor Plan

4. How to Create & Apply View Filters.

5. How to Create & Apply View Template.

6. How to Create & Edit Sheets.

7. How to Create a Detailed Section View

8. How to Create an Equipments Schedule Sheet.

9. How to Create a Drawing List to Add Revisions on Sheet

11.printing & Plotting Settings in Revit.

12.converting Revit to Pdf

13.converting Revit to Cad

Who This Course Is for:

Mechanical Eeers, Electrical Eeers , Architects

Mep Professionals

Hvac Eeers

Piping Eeers
